Sinocat Diesel Generator Three Way Catalysts Converter 300 CPSI
-
High Light
Sinocat Three Way Catalysts Converter
,Sinocat catalytic converter for diesel generator
,catalytic converter for diesel generator 300 CPSI
-
Substrate MaterialMetal
-
CoatingPrecious Metal
-
Emission StandardEPA
-
Cell Density100, 200, 300, 400 CPSI
-
ApplicationGasoline Generator
-
ColorAs Per Requirement
-
Housing MaterialSteel
-
Place of OriginChina
-
Brand NameSinocat
-
CertificationIATF 16949 ISO 9001
-
Model NumberGenerator Catalyst
-
Minimum Order Quantity50 Pcs
-
PriceAs per specification.
-
Packaging DetailsCarton in Pallet
-
Delivery Time30 Days
-
Payment TermsL/C, T/T
-
Supply Ability500,000 pcs per month.
Sinocat Diesel Generator Three Way Catalysts Converter 300 CPSI
Generator Three Way Catalyst Convertor
Generator threee way catalyst convertors are used to reduce HC, CO and NOx from diesle, natural gas and gasoline generators.
The utilization of catalysts help to improve emissions of generator fume thus to achieve environmental friendliness.
Features of Generator Three Way Catalyst Convertor:
Ø High skill coating techniques ensure solid, long lasting and stable catalytic performance.
Ø Advanced technology and packaging techniques carriers to ensure reliable thermal shock and mechanical stability.
Ø Catalyst substrates: Honeycomb ceramic or metal substrates.
Ø Catalyst: Combinnation of platinum, palladium, rhodium, other precious metals and rare earth elements.
Ø Customized generator three way catlayst convertors are available.
Ø Compatibility with different generators.
Ø Conform to Euro III, Euro IV, Euro V, Barat Standard IV, BS V, BS VI, CARB, EPA standards.
Technical Parameters
| Description | Light-off Temperature | Durability | Conversion Efficiency | Coating Desquamate Rate |
| Generator Three Way Catalyst Converter | T50(CO)≤230 T50(HC)≤260 T50(NOX)≤250 | 40000-50000KM | CO≥85% HC≥80% CO≥85% | ≤7% |
Dimensions & Cell Density (CPSI):
| Dimensions(mm) | Cell Density (CPSI) | Coating Thickness(mm) |
|
Diameter: 28mm - 550mm Length: 50mm - 300mm |
50, 100, 200,250,300,400,500,600, | 0.03, 0.04, 0.05, 0.06, 0.08, 0.10 |
With high specific surface area alumina and high oxygen storage rare earth materials as carriers, Pt/Pd/Rh precious metals as active components, it is accurately controlled by quantitative coating method, and the conversion efficiency of CO, HC, NOx is ≥90%, and has excellent anti-aging properties. The products meet the requirements of Euro 4/Euro 5 regulations, and can develop special types and structures of catalysts according to the special needs of customers.
Metallic substrate has the advantages of fast burning, small volume, high mechanical strength, prominent heat-resistance, etc. It is widely used in exhaust gas purification, especially for motorcycle. We can make 100CPSI, 200CPSI, 300CPSI, 400CPSI AND 600CPSI honeycomb metallic substrate in various shapes, such as round, oval, racetrack and other customized shapes. We constantly improve the quality and service. Our products get high reputation from customers.
| Specification | Cell Density (CPSI) | Emission Standard |
| 25*50*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 28*40*30 | 100/200/300/400 | Euro 4, Euro 5 |
| 28*60*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 28*100*90 | 100/200/300/400 | Euro 4, Euro 5 |
| 30*20*20 | 100/200/300/400 | Euro 4, Euro 5 |
| 30*30*30 | 100/200/300/400 | Euro 4, Euro 5 |
| 32*25*25 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*30*30 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*32*32 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*40*30 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*45*45 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*50*40 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*52*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*60*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*70*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*70*60 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*100*40 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*100*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*100*60 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*100*80 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*100*90 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*120*110 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*130*120 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*140*110 | 100/200/300/400 | Euro 4, Euro 5 |
| 35*200*180 | 100/200/300/400 | Euro 4, Euro 5 |
| 36*100*100 | 100/200/300/400 | Euro 4, Euro 5 |
| 38*100*100 | 100/200/300/400 | Euro 4, Euro 5 |
| 39*60*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 40*60*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 40*80*80 | 100/200/300/400 | Euro 4, Euro 5 |
| 41*100*100 | 100/200/300/400 | Euro 4, Euro 5 |
| 42*45*45 | 100/200/300/400 | Euro 4, Euro 5 |
| 42*50*40 | 100/200/300/400 | Euro 4, Euro 5 |
| 42*50*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 42*60*40 | 100/200/300/400 | Euro 4, Euro 5 |
| 42*60*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 42*100*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 42*100*60 | 100/200/300/400 | Euro 4, Euro 5 |
| 42*100*80 | 100/200/300/400 | Euro 4, Euro 5 |
| 42*100*90 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*60*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*60*60 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*75*70 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*80*70 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*100*90 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*110*100 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*110*85 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*110*90 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*112*100 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*112*40 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*112*60 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*120*80 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*130*120 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*140*101.6 | 100/200/300/400 | Euro 4, Euro 5 |
| 45*150*140 | 100/200/300/400 | Euro 4, Euro 5 |
| 50*100*100 | 100/200/300/400 | Euro 4, Euro 5 |
| 50*50*40 | 100/200/300/400 | Euro 4, Euro 5 |
| 52*100*90 | 100/200/300/400 | Euro 4, Euro 5 |
| 52*105*85 | 100/200/300/400 | Euro 4, Euro 5 |
| 52*105*85 | 100/200/300/400 | Euro 4, Euro 5 |
| 52*110*90 | 100/200/300/400 | Euro 4, Euro 5 |
| 52*125*85 | 100/200/300/400 | Euro 4, Euro 5 |
| 52*125*85 | 100/200/300/400 | Euro 4, Euro 5 |
| 60*62*60 | 100/200/300/400 | Euro 4, Euro 5 |
| 60*75*65 | 100/200/300/400 | Euro 4, Euro 5 |
| 62*160*150 | 100/200/300/400 | Euro 4, Euro 5 |
| 62*60*50 | 100/200/300/400 | Euro 4, Euro 5 |
| 71*99*74.5 | 100/200/300/400 | Euro 4, Euro 5 |
| 71*99*79 | 100/200/300/400 | Euro 4, Euro 5 |
| 72*120*110 | 100/200/300/400 | Euro 4, Euro 5 |
| 72*50*40 | 100/200/300/400 | Euro 4, Euro 5 |
| 72*85*75 | 100/200/300/400 | Euro 4, Euro 5 |
| 72*85*75 | 100/200/300/400 | Euro 4, Euro 5 |
| 80*65*50 | 100/200/300/400 | Euro 4, Euro 5 |
| Remark: | Can be designed as per client's requirement. | |
